LT588
EN 856-4SH | MSHA | MA Wire Spiral Hydraulic Hose
Hose Construction & Applications
- Inner Tube: Black oil resistant synthetic rubber
- Reinforcement: Four plies of spiraled high tensile steel wire
- Outer Layer: Black oil and weather resistant synthetic rubber
- Temperature Range: -40°C to +100°C (-40°F +212°F)
- Application: Suitable for conveying water-based,petroleum-based, and biodegradable hydraulic oil.
Description
Technical Specifications
|
Specification |
Specification |
I.D |
W.D |
O.D |
Max.W.P |
P.P |
Min.B.P |
Min.B.R |
W.T |
|||
|
SIZE |
SIZE |
Min |
Max |
Min |
Max |
Min |
Max |
|||||
|
DASH |
IN |
mm |
mm |
mm |
mm |
mm |
mm |
MPa |
MPa |
MPa |
mm |
kg/m |
|
-10 |
5/8 |
15.5 |
16.7 |
23.9 |
25.1 |
26.0 |
28.0 |
45 |
90 |
180 |
250 |
1.15 |
|
-12 |
3/4 |
18.6 |
19.8 |
27.6 |
29.2 |
30.0 |
32.0 |
42 |
84 |
168 |
280 |
1.54 |
|
-16 |
1 |
25.0 |
26.4 |
34.4 |
36.0 |
37.0 |
39.0 |
38 |
76 |
152 |
340 |
2.02 |
|
-20 |
1 1/4 |
31.4 |
33.0 |
40.9 |
42.9 |
43.8 |
46.2 |
32.5 |
65 |
130 |
460 |
2.48 |
|
-24 |
1 1/2 |
37.7 |
39.3 |
48.1 |
50.1 |
51.3 |
53.7 |
29 |
58 |
116 |
560 |
3.18 |
|
-32 |
2 |
50.4 |
52.0 |
62.2 |
64.2 |
65.3 |
67.7 |
25 |
50 |
100 |
700 |
4.46 |
The items marked with * are for reference only; the actual specifications are subject to the hose body.
