LT800A
LCP-Water Manifold Jumper Hose
Hose Construction & Applications
- Inner Tube: EPDM rubber cured with peroxide
- Reinforcement: One layers of braided synthetic fiber
- Outer Layer: Black weather-resistant, ozone-resistant, UL94V0 flame-retardant special synthetic rubber
- Temperature Range: -40°C~+120°C (-40°F~+248°F)
- Color: Red、black、blue
- Application: Suitable for medium fluids such as air, water, water glycol, oil-water emulsion, antifreeze, phosphate ester hydraulic oil, etc.
Description
Technical Specifications
|
Size |
|
|
|
|
|
|
|
|
DASH |
IN |
mm |
mm |
MPa |
MPa |
mm |
kg/m |
|
-4 |
1/4 |
6.4 |
12.1 |
1 |
4 |
25.4 |
0.13 |
|
-5 |
5/16 |
7.7 |
14.5 |
1 |
4 |
31.5 |
0.18 |
|
-6 |
3/8 |
9.5 |
15.9 |
1 |
4 |
38.1 |
0.19 |
|
-8 |
1/2 |
12.7 |
19.8 |
1 |
4 |
69.9 |
0.25 |
|
-10 |
5/8 |
15.9 |
23.1 |
7 |
4 |
88.9 |
0.30 |
|
-12 |
3/4 |
19.1 |
26.2 |
1 |
4 |
114.3 |
0.35 |
|
-16 |
1 |
25.4 |
32.6 |
0.7 |
2.8 |
152.4 |
0.52 |
|
-20 |
1 1/4 |
31.8 |
43 |
0.7 |
2.8 |
195 |
0.70 |
The items marked with * are for reference only; the actual specifications are subject to the pipe body.
