LT304
Multi-Purpose Crude Oil Hose
Hose Construction & Applications
- Inner Tube: Polymer composites
- Reinforcement: Multi-spiraled high tensile texile cords and highly flexible steel helix wire
- Outer Layer: Synthetic rubber
- Temperature Range: -40°C~+180°C (-40°F~+356°F)
- Application: The hose is suitable for delivering petroleum products such as fuel oil, crude oil, gasoline, etc. The hose inner layer is made of polymer composites, which makes the hose with strong corrosion resistance and high lubrication characteristics. Its excellent chemical stability prevents it from reacting with chemical substances in petroleum products,ensuring safe and efficient transportation of the medium.
Description
Technical Specifications
*The hose dimension, pressure and color can be customizedbased on the requirements.
|
I.D. |
W.P |
Safety Factor |
|
|
in. |
mm |
MPa |
|
|
2 |
51 |
2-35 |
2.5times |
|
2 1/2 |
63 |
2-35 |
2.5times |
|
3 |
76 |
2-35 |
2.5times |
|
3 1/2 |
90 |
2-35 |
2.5times |
|
4 |
102 |
2-35 |
2.5times |
|
5 |
127 |
2-35 |
2.5times |
|
6 |
152 |
2-35 |
2.5times |
Note: Actual parameters are subject to the latest catalog.
