LT801
Wire Braid Air Hose
Hose Construction & Applications
- Application: Designed for higher pressure air transfer services in construction and mining industries,suitable for extremely environment because of its abrasion resistant characteristic
- Inner Tube: Black NR&SBR synthetic rubber
- Reinforcement: One braid of high tensile super flexible steel wire
- Outer Layer: Black or yellow NR&SBR synthetic rubber
- Temperature Range: -30℃~82℃(-22°F~180°F)
Description
Technical Specifications
*The hose dimension,pressure and color can be customized based on the requirements
|
I.D. |
O.D. |
W.P |
Min.B.P |
Min.B.R. |
W.T |
||
|
in |
mm |
in |
mm |
psi |
psi |
mm |
kg/m |
|
1/2 |
13 |
0.87 |
22 |
600 |
2400 |
180 |
0.42 |
|
3/4 |
19 |
1.10 |
28 |
600 |
2400 |
240 |
0.55 |
|
1 |
25 |
1.34 |
34 |
600 |
2400 |
300 |
0.70 |
|
1-1/4 |
32 |
1.65 |
42 |
600 |
2400 |
420 |
1.07 |
|
1-1/2 |
38 |
1.89 |
48 |
600 |
2400 |
500 |
1.28 |
|
2 |
51 |
2.52 |
64 |
600 |
2400 |
630 |
1.99 |
|
2.5 |
64 |
3.26 |
77 |
450 |
1800 |
800 |
2.44 |
|
3 |
76 |
3.54 |
90 |
450 |
1800 |
920 |
2.90 |
|
4 |
102 |
4.65 |
118 |
450 |
1800 |
1300 |
5.16 |
